Recovery Points for
Lexus GX470 (2003-2005)
Toyota 4th Gen 4Runner
Each side uses 1 x M12x1.25x100L & 1 x M12x1.25 x 50L bolts .
Hi tensile bolts supplied, with relevant flat & split washer. The longer bolts are for the TOP hole of the tow point mount holes. Installation of this 100mm long bolt requires the radiator to be moved backwards to allow for the bolt to be inserted from the radiator side of the chassis rail. You do not need to completely disconnect the radiator.
A flat washer should be used with the bolt head, with the bolt secured with a flat washer & nyloc nut.
The 50mm long bolt is for the LOWER hole of the tow point mount hole. This 50mm long bolt enters the tow point and secures into the factory nut in the chassis. A flat washer and split washer should be used with the bolt head.
Ensure both bolts per tow point are fitted and torqued to recommended settings to ensure tow points meet tested standards.
FOR YOUR SAFETY
- Do not use with soft shackles
- Only front loading
